Canyon Ridge Faux



The Canyon Ridge Faux garage door is available in two different collections,
LIMITED EDITION SERIES or ULTRA-GRAIN^® SERIES

CANYON RIDGE^® COLLECTION LIMITED EDITION SERIES

• Five-layer construction: steel + insulation + steel + cladding + overlay
• Available with 2"- polyurethane insulation with an R-Value of 20.4*
• Swing-out appearance, overhead operation
• Fourteen base designs with optional windows and decorative hardware
• Over 200 unique style combinations
• Factory finished in either Medium or Dark finishes. Can be field stained.



1. COMPOSITE OVERLAY
2. COMPOSITE CLADDING
3. STEEL
4. 2" POLYURETHANE INSULATION
5. STEEL



Half-inch thick polymer composite cladding and overlay materials are molded from actual wood  to replicate the species' natural texture and intricate grain patterns as well as its imperfections, like deep, irregular pockmarks, knots, cracks, and holes. Lightweight, durable and easy to maintain, once installed, these rustic beauties are virtually indistinguishable from the original.



__________________________________________________________________________________

1. COMPOSITE OVERLAY
2. STEEL WITH ULTRA-GRAIN PAINT FINISH
3. 2" POLYURETHANE INSULATION
4. STEEL



Glazing

• 1/8" DSB glass standard.
• Obscure, seeded, insulated DSB, insulated obscure and insulated seeded glass optional. (Insulated glass available on certain models only.).
• Attractive beveled edge clip-in grilles are removable for easy cleaning.



• Proper care and maintenance are imperative to the appearance, longevity and performance of your Clopay Canyon Ridge Collection garage door.


  ____________________________________________________________________________________




  = Cast Iron Construction.      = Aluminum Construction
